Metz MECABLITZ 64 AF-1 digital Canon - Manual (Page 186)

10.2 Remote slave flash mode
The flash unit supports Canon`s wireless
E TTL Remote System in slave flash mode. At
the same time, one or more slave flash units
can be remotely controlled from one master
flash unit on the camera (e.g. mecablitz 5
64AF-1C digital).
A slave flash unit can be assigned to one of
three possible slave groups (GROUP A, B or
C). The master flash unit can control all of
these slave groups simultaneously and at the
same time take the settings for each slave
group into account.
So that multiple remote systems in the same
room do not interfere with one another, there
are four independent remote channels avai-
lable (CH 1, 2, 3 or 4).
Master and slave flash units belonging to the
same remote system must be set to the same
remote channel.
The slave flash units must be able to receive
the light from the master flash unit with the
integrated sensors for the remote mode .
Depending on the camera model, the came-
ra’s internal flash unit can also function as
master flash unit.
10.2.1 Remote slave flash mode settings
• Switch on the flash unit with the
ባ
button. The start screen appears.
Thereafter, the flash unit always switches
on with the mode of operation that was
used last (e.g. ETTL flash mode).
• Press the displayed mode of operation on
the touch display as many times as it takes
for the display for selecting the mode of
operation to appear.
• Press the sensor buttons on the
touch display and select .
• Press the s ensor button on
the touch display.
Remote slave mode is set.
In addition, the selected slave group (e.g. A)
and the remote channel (e.g. CH 1) are dis-
played.
REMOTE SLAVE
REMOTE SLAVE
186
0.6- 7.2 m
F
5,6
M-
Zoom 35 m
m
ETTL
i
EV
MODE
O
q p
REMOTE MASTER
REMOTE SLAVE
SERVO
M-
Zoom 35
REMOTE
SLAVE
Gr Ch
A 1
i
m
m
EV
k
