11.3 Secondary reflector (SUB-REFL.)
The secondary reflector is used for frontal
brightening when using a bounce flash if the
main reflector is tilted sideways or upwards.
If the light from the secondary reflector is too
large, it can be reduced by half.
Setting procedure
• Press the ቨ button as often as it takes
for the selection menu to appear.
• Press the sensor button on the
touch display.
• Press the sensor buttons on the
touch display and select .
• Press the sensor button on the
touch display.
• Press the , or sensor but-
ton on the touch display and switch the
secondary reflector on or off. The setting is
adopted immediately.
Upon switching on the secondary reflector,
appears on the display
„ 1/1” or „ 1/2” is displayed in the INFO
menu.
1/1 means full light output, 1/2 means half
light output.
SUB-REFL.
SUB-REFL.
OFF 1/2 1/1
D
OPTION
11.4 Modelling light
The modelling light is a high-frequency stro-
boscopic flash. It creates the impression of a
semi-permanent light for a duration of about
3 seconds. The modelling light enables the
user to assess light distribution and the for-
mation of shadows before taking pictures.
The modelling light is triggered with the
manual firing button
ቧ.
Setting procedure
• Press the ቨ button as often as it takes
for the selection menu to appear.
• Press the sensor button on the
touch display.
• Press the sensor buttons on the
touch display and select .
• Press the sensor button on the
touch display.
• Press the or sensor button on
the touch display and switch the modelling
light on or off. The setting is adopted
immediately.
After activation of the modelling light, „
” appears in the INFO menu.
MOD. LIGHT
MOD. LIGHT
OFF ON
D
OPTION
OPTION
SUB-REFL.
O
OFF
1/1
1/2
OPTION
O
q p
RAPID
SUB-REFL.
ZOOM SIZE
MOD. LIGHT
O
OFF
ON
OPTION
O
q p
OPTION
OPTION
q p
MOD. LIGHT
BEEP
RAPID
SUB-REFL.
STANDBY
