Python ® LX Fronius Compatible ™ Owner's Manual - Page 14
Python LX Fronius Compatible
Front Body Assembly
P/N 003-2271 (Air Cooled)
P/N 003-2108 (Water Cooled)
Front Body Assembly
No. Qty. Part No. Description
1 - -
Not available separately
2 - -
3* 1 325-0206 10-24 x 3/8 PH Screw
4* 1 333-0082 # 10 Lock Washer
5 1 419-0092 0.29 x 0.047 x 0.32 Comp. Spring
6 1 421-0525 1/8 x 7/8 SST Dowel Pin
7 1 431-1663 Idler Adjusting Screw
8 1 431-1598 Idler Arm
9 1 511-0001* Idler Wire Feed Assembly
10 1 511-0101 Drive roll
* Items 3, 4 & 9 available as package kit: Part number 005-0686
