Python ® LX Fronius Compatible ™ Owner's Manual - Page 28
Python LX Fronius Compatible
Power Manifold Assembly, Push Fitting
Water Cooled, P/N 003-2378
Liquid Cooled Power Manifold Assembly
No. Qty. Part No. Description
1 1 303-0097 O-Ring Buna-N .101 ID x .07W
2 1 321-1104 Set Screw Conduit
3 2 431-1905 Fitting 1/8 ID x 1/16 - 27 NPT
4 1 431-1948 Connector Thread
5 - - Not available separately
APPLY LOW STRENGTH THREAD LOCKING TO EXTERNAL THREADS
BEFORE INSTALLATION.
APPLY SILICONE LUBRICANT
FOR INSTALLATION.
APPLY HIGH STRENGTH THREAD SEALANT
TO THREADS
