Python ® LX Fronius Compatible ™ Owner's Manual - Page 17
*Apply silicone lubricant to
items 4 and 5 before installing.
Air Cooled 60º Curved Barrel Assembly
No. Qty. Part Number Description
1 - - Not available separately
2 1 003-2213 Assy Taper Lock Barrel
3 1 261-0143 Insulator Barrel
4* 2 303-0010 O-Ring .489 ID x .07 W
5* 2 303-0094 O-Ring .301 ID x .07 W
6 1 313-0091 Retaining Ring 5/8 Shaft
7 1 431-1774 Cup Insulator Barrel
8 0.63 ft 615-0178 Liner Tef 0.084 ID x 0.174 OD
9 1 621-0250 Assy Cup Copper Finned #10
10 1 621-0393 Tip HD Spray .060
Python LX Fronius Compatible Barrel Assembly
Air Cooled
P/N 003-2272
