Nortec DRAABE Pure Water System - Manual (Page 20)

Created: 21.09.2006
Changed: 29.02.2008
Printed: 02.03.2009
page 20 of 59
(5) electrical fuse for the motor of the pump
(1) main switch (ON/OFF), illuminated
(3) manometer
(4) safety switch operating pressure
120VAC, 60Hz
to the
standing storage tank
(2) float valves
Figure 9: Pressure boost (upper part)
EIN
AUS
Sic her ung
1A
