MAKING CONNECTIONS ON AN X3 HVR
Connecting a Video Source
There are different types of Video Sources that can be plugged into the HVR including DVD players,
VHS players, and CCTV Cameras. The back of the HVR contains up to 16 video inputs depending on
the HVR model. The connectors use the BNC standard.
8 Channel HVR
16 Channel HVR
The video inputs are 75 Ώ BNC connectors. Plug one end into the video source (DVD, Camera, etc.)
and plug the other end into the desired BNC input on the HVR unit.
