REMKO WKF-120-180Duo Electrical wiring - Manual (Page 27)

S01 GND
-SMTIO1
S01.1
Probe PT1000
1 2
-S01.1
Collector probe
PT1000
S02 GND
-SMTIO1
S02.1
Probe PT1000
1 2
-S02.1
Storage tank, bottom
PT1000
S03 GND
-SMTIO1
S03.1
Probe PT1000
1 2
-S03.1
Solar inlet
PT1000
S04 GND
-SMTIO1
S04.1
Probe PT1000
1 2
-S04.1
Solar return flow
PT1000
S05 GND
-SMTIO1
S05.1
Probe PT1000 / impulse sensor
1 2
-S05.1
Circulation
PT1000
F
1 2
-S05.1
Circulation
Impulse sensor
S06 GND
-SMTIO1
S06.1
Probe PT1000
1 2
-S06.1
2nd mix. heating cycle inlet
PT1000
S07 GND
-SMTIO1
S07.1
Probe PT1000
1 2
-S07.1
Refrigerant - liquid
PT1000
- Collector probe
red
whi
-Tank probe
red
whi
-Solar inlet
red
whi
-Solar return flow
red
whi
-Circulation
red
whi
- 2nd mix. HC inlet
red
whi
-Refrigerant
red
whi
Circulation, elective
Changed:
Replaced by
Standard Date of creation
Origin
001
Drafted by
Checked:
Date of issue:
Sheet title Project title
1.0
mweiss
Status:
0
1
2
3
4
5
6
7
8
9
10
11
0
1
2
3
4
5
6
7
8
9
10
11
Sheet/tot.
12/17/2013
Sheet
System
mweiss
Probes
Edition Customer:Remko
vlöchte
WKF-DUO Project:
8
4/14/2014
Edited
11/52
Replacement for
WKF DUO 120/180
Temperature or impulse
-
controlled via a flow switch
27
