Skutch Electronics BA-1000-A V1.15 - Manual (Page 8)

Version 1.15 Page 8
Power Up
To power the unit up;
1) Make sure that the Microphone is disconnected
from the BA-1000-A.
2) Connect the supplied POWER ADAPTER to the
POWER jack on the rear panel of the BA-1000-
A. This MUST be done before the POWER
ADAPTER is connected to 115VAC power.
3) Now connect the POWER ADAPTER to a
115VAC 60Hz power outlet.
Change the Time
To change the current time and/or date, do the
following:
Press: ~ ~ ~ ~.
Wait 5 seconds.
Enter:
8 8 8
8 8 8 8 8 8 8 8 8
Wait 5 seconds.
Press:
1 1 1 1.
Enter the day of the week, then # # # #; example:
1 1 1 1 = Sunday, 2 2 2 2 = Monday, etc.
Enter the new date then # # # #.
Enter the current time then # # # #; you change
between a.m. and p.m. with the * * * *. Example: 1:32
is 0132# 0132# 0132# 0132#.
Wait 5 seconds then press ~ ~ ~ ~.
Record Outgoing
Message
Plug microphone into MIC IN jack.
Press:
~ ~ ~ ~.
Now press and HOLD DOWN: 5 5 5 5.
For BEST audio quality, hold the microphone 3
inches away from your mouth; when tone stops,
immediately dictate your message.
When finished, release the 5 5 5 5 to hear the
message.
Unplug the microphone.
Sample Outgoing Message
"ABC Productions! I'm sorry but we are not
available to answer your call at this time. If you
need immediate assistance, please leave your
message then dial
8 8 8 8 on your telephone and we
will return your call very shortly. Thank you."
Test Outgoing
Message
Press: ~ ~ ~ ~.
Press and HOLD DOWN the 6 6 6 6 until the unit
Beeps.
Release the 6 6 6 6 to hear the message.
Locally Program
Notification
Phone Numbers
Press: ~ ~ ~ ~.
Wait 5 seconds.
Enter:
1 2 3
1 2 3 1 2 3 1 2 3
Wait 5 seconds.
Press:
# # # #.
For this example we are entering a home phone
number, then a pager phone number.
