30-007 CHEMICAL CLEANLOAD DRAWING
REF# PART # DESCRIPTION QUANTITY
1 16-156 Elbow 2
2 8897-125 1 1 /
4
" Discharge Hose 125" 1
18-116 Hose Clamp 2
3 18-391 Coupling 1
4 16-972 90° Elbow 1
5 15-620 Cleanload Assembly 1
6 8897-38 1 1 /
4
" Discharge Hose 38" 1
18-116 Hose Clamp 2
7 17-535 Clean Load Mount (part of boom) 1
8 16-945 Fitting (part of tank) 1
9 16-971 45° Elbow (part of tank) 1
10 16-161 Fitting 1
