Mechanical Interface: TIM Standard
This module conforms to the TIM standard (
Texas Instrument Module, See
) for single width modules.
It sits on a carrier board.
The carrier board provides power, Ground, communication links (Comport links)
between all the modules fitted and a pathway to the host, for a non stand-alone
system.
The SMT398 requires an additional 3.3V power supply (as present on all Sundance
TIM carrier boards), which must be provided by the two diagonally opposite mounting
holes.
SMT398 Support
The SMT398 is supported by the SMT6500 software package available from
SUNDANCE. Please register on SUNDANCE
Then enter your company’s forum and you can request the SMT6500 from there.
SMT398 Installation
Do NOT connect any external TTL (5v) signals to the SMT398 I/Os as the FPGA
is NOT 5v compliant. This implies that the Comports and global bus lines of
the carrier board MUST be LVTTL and that any device driving signals on the
SHB connectors must drive at LVTTL (3.3v).
Two types of configuration are described here; nevertheless, you shouldn’t be
restricted and should consult Sundance if your system architecture differs.
SMT398 Alone
You can fit the SMT398 on its own, on the first TIM site of one of Sundance’s 3.3v
compatible carrier boards plugged in a host computer (PC, PCI, VME carrier etc…),
like SMT310Q, SMT328, SMT300 etc…)
Please, follow these steps to install the SMT398 module on a Host system:
1. Remove the carrier board from the host system.
2. Place the SMT398 module on the first TIM site. This TIM site communicates
with the host. (See your carrier board User Manual.) This allows you to use
Global Bus and Comport 3 to communicate with the host.
