19
EN
Specifications
Frequency response . . . . . . . . . . . . . . . . . . . . . 10 Hz – 80 kHz (when using LINE IN)
Distortion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0.004%
(32 Ω, 1 kHz, 100 mW + 100 mW output, JEITA)
Supported headphone impedance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8–600 Ω
Maximum input (LINE IN) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Vrms
Effective maximum headphone output
170 mW + 170 mW (32 Ω, 1 kHz, 10%, JEITA)
80 mW + 80 mW (300 Ω, 1 kHz, 10%, JEITA)
40 mW + 40 mW (600 Ω, 1 kHz, 10%, JEITA)
Operating temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0°C to 35°C
Continuous battery operation time
(when load is 32 Ω, output is 1 mW + 1 mW and PWR MODE=LOW)
Apple iOS device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . About 7 hours
o The operation time when using batteries will differ depending on use and
other conditions.
Charging time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . About 9 hours (using USB)
About 4 hours (using PS-P515U with DC input)
External dimensions . . . . . . . . . . . . 69.6 × 123 × 21.5 mm (2 3/4” × 4 7/8” × 7/8”)
(W × D × H, not including protrusions)
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 280 g (5/8 lb)
Supported sampling frequency/bit depth. . . . . . . . . . PCM: up to 192 kHz/24-bit
DSD: up to 5.6448 MHz/1-bit
Recommended AC adapter . . . . . . . . . . . . . . .TASCAM/PS-P515U (sold separately)
Compatible media . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . microSD cards (64 MB – 2 GB)
microSDHC cards (4 GB – 32 GB)
microSDXC cards (64 GB – 128 GB)
o Not all media are necessarily compatible with this unit. Check the “HA-P90SD
tested media list” on the TEAC Global Site (http://teac-global.com/) for infor-
mation about compatible media.
Supported file systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . FAT16, FAT32, exFAT
Included accessories
DC power supply cable (DC plug to USB A connector) × 1
USB cable for computer connection
(USB micro-B connector to USB A connector) × 1
RCA conversion (RCA to mini plug) cable × 1
Rubber bands for attachment × 2
Owner’s manual × 1
o Design and specifications are subject to change without notice.
o Weight and dimensions are approximate.
o Illustrations may differ slightly from production models.
