Using the Craft Interface
Craft-6 Verilink Craft Interface
• A letter followed by a parenthesis, A), indicates a user-settable
option.
Selecting an
Element
To select an element in the node to manage, select the command
option for choosing the shelf and slot:
S) shelf/slot
as shown in the following example command line:
[0.0.0.1] [1,1] NCM 2000 > s
The next prompt shows you the format for your input.
For SCM and NCM :
Enter 'shelf,slot' pair or 'slot' in current shelf (e.g. 3,4 or 5): >
For SCC and NCC:
Enter 'shelf,slot' pair (e.g. 3,4 or 5): >
This prompt varies from product to product. Select the shelf and
slot location of the module to manage. In the example in Figure 3,
suppose you wish to configure a port on the DIDCSU located in
shelf 2, slot 3. This element is represented by an A, which the Key
below the shelf/slot display identifies as a DIDCSU. You would type
in response to the prompt: “2,3”.
To indicate a successful selection, the Main Menu is redisplayed
with bracket-indicator [ ] moved to enclose the A.
Figure 3 Main Menu) with DIDCSU module selected
-- VERILINK NCM CONTROLLER : FW Rev 4.17, Dec 30 1997 16:55:20 --
Site Name: Test1 Access Level: 2
Managing at NEAR end node [0.0.0.1] Node ID: 3141
<- SLOT ->
SHELF 1 2 3 4 5 6 7 8 9 10 11 12 13
0 - - - - - - - - - - - - -
1 M N *N - - Q M Q Q M - - - -
2 M A A [A] A A A A A A A A - -
3 - - - - - - - - - - - - -
4 - - - - - - - - - - - - -
KEY: A=DIDCSU, B=DIU/DBU, C=CSU, D=DIU, E=SDIU, F=DIU/DDS, G=DHDM,
H=ATM/IMUX, I=IDCSU, J=PEP, K=DAC, L=HLM, M=IMUX, N=NCM, P=DPRI,
Q=QUAD, R=SUBRATE, S=HSM, T=HDM, U=DCSU, V=VCU, X=QPRI
S) shelf/slot O) administration
C) configuration D) diagnostics
P) performance/status A) alarm
B) circuit manager I) manufacturing info
X) exit this screen
A [0.0.0.1] [2,3] DIDCSU >
