27
PROGRAMMING GUIDE
START
The START bar code places the reader into the program mode. After
scanning this label, the reader will emit three short BEEPS to indicate that it is
in the program mode.
EXIT (SAVE CHANGES)
Scan this bar code to EXIT the program mode and save all of the changes.
After scanning this label, the reader will BEEP twice then delay
approximately one second and emit three short BEEPS to indicate that it
accepted the changes.
EXIT (IGNORE CHANGES)
Scan this bar code to EXIT the program mode and DISCARD all of the
current changes. The reader will use the settings that were in effect before
entering the program mode.
RESET ALL DEFAULTS
Scan this bar code to RESET all options to their DEFAULT settings.
NOTE: Defaults are marked with "*".
0-9 BAR CODES
These bar codes are scanned to select various options and enter
programmable data into the reader.
NOTE: Scan option (9) to reset all of the options within the
current CATEGORY back to their defaults.
ON
If the OPTION has an (ON/OFF) beside the description, scan the ON bar code
to turn ON the current option.
OFF
If the OPTION has an (ON/OFF) beside the description, scan the OFF bar
code to turn OFF the current option.
FULL ASCII CHART
The FULL ASCII CHART is located on the back of the READER SETUP
MENU. This chart contains the entire ASCII character set (128
characters). Use this chart to enter PREAMBLE and POSTAMBLE
character strings as well as the RECORD TERMINATOR and
SEPARATOR characters.
ADDITIONAL NOTES:
If the description beside the OPTION contains:
(ON/OFF) Then scan either an ON or OFF label to set the option.
(CHART) Then scan one or more characters from the Full ASCII Chart.
(0-9) Scan the disired character from the 0-9 labels.
(0.0-9.9) Scan two characters from the 0-9 labels to set the time from 0
to or (0.0-99) 9.9 seconds, or 0 to 99 seconds.
