102
Gigabit SFP
module
Central
wavelength Connector
Cable
specifications
Mode
bandwidth
Maximum
transmission
distance
SFP-GE-LH70-S
M1490-CW
1490 nm LC
9/125 μm
single-mode
optical fiber
N/A 70 km (43.50 miles)
SFP-GE-LH70-S
M1510-CW
1510 nm LC
9/125 μm
single-mode
optical fiber
N/A 70 km (43.50 miles)
SFP-GE-LH70-S
M1530-CW
1530 nm LC
9/125 μm
single-mode
optical fiber
N/A 70 km (43.50 miles)
SFP-GE-LH70-S
M1550-CW
1550 nm LC
9/125 μm
single-mode
optical fiber
N/A 70 km (43.50 miles)
SFP-GE-LH70-S
M1570-CW
1570 nm LC
9/125 μm
single-mode
optical fiber
N/A 70 km (43.50 miles)
SFP-GE-LH70-S
M1590-CW
1590 nm LC
9/125 μm
single-mode
optical fiber
N/A 70 km (43.50 miles)
SFP-GE-LH70-S
M1610-CW
1610 nm LC
9/125 μm
single-mode
optical fiber
N/A 70 km (43.50 miles)
IMPORTANT:
You must use the SFP-GE-LX-SM1310-BIDI and the SFP-GE-LX-SM1490-BIDI in pairs.
Table 37 QSFP+ module specifications
QSFP+ module Central
wavelength Connector
Cable
specifications
Modal
bandwidth
Maximum
transmission
distance
QSFP-40G-SR4-
MM850
850 nm
MPO (PC
polished,
12-fiber) 50/125 μm
multimode
optical fiber 2000 MHz*km 100 m (328.08 ft)
4700 MHz*km 150 m (492.13 ft)
QSFP-40G-CSR
4-MM850
850 nm
MPO (PC
polished,
12-fiber)
50/125 μm
multimode
optical fiber
2000 MHz*km 300 m (984.25 ft)
4700 MHz*km 400 m (1312.33 ft)
QSFP-40G-LR4-
PSM1310
1310 nm
MPO (APC
polished,
12-fiber)
9/125 μm
single-mode
optical fiber
N/A 10 km (6.21 miles)
QSFP-40G-LR4-
WDM1300
1310 nm LC
9/125 μm
single-mode
optical fiber
N/A 10 km (6.21 miles)
