2000NET Instruction Manual
Using the 2000NET GUI
Frame Interface
This section describes GUI functions for the frame.
Frame Status Web Page
The Frame Status web page (
for a 3 RU frame and
for a 1 RU frame) displays an overall status for the
frame. This includes status for each device, module, empty slot, power
supply, and the 2000NET and 2000GEN modules.
Note
2000 and legacy Thomson Grass Valley modules that can reside in the
2000T3 frame are supported to different degrees by the 2000NET module.
The status of modules, empty slots, power supplies, and the 2000NET
board are presented in icons arranged from left to right as they are in the
physical frame. Each icon also provides a clickable link to the device’s
status page.
Note
When the 2000NET is first installed or when many modules are installed
simultaneously, it may take some time for the 2000NET to poll, update status,
and build the HTML pages. This is especially true if there are modules that fail
frame bus reporting. During these periods the Frame Status Page may fall
behind temporarily until the 2000NET board can catch up and present a true
current status.
During initial polling, modules that do not respond immediately may tran-
sition to a
WARNING, MODULE NOT RESPONDING
status. In this case, this is a tem-
porary status until a maximum number of sequential attempts fail and a
Fault is reported.
Module Slot Status
Module Slot Status icons report one of the following:
Table 5. Module Status Indicators
Icon
Color
Module
Status
Icon
Text
Indication
White
None
Empty
No module detected in slot.
Grey
No Comm No Comm Slot contains a legacy module which was not designed to support Frame
Bus communications with an 2000NET module.
Green
Pass
Module
Slot contains a fully Frame Bus capable module.
Yellow
Warning
Module
2000NET has detected a warning condition in module due to lack of input
signal or incomplete support for remote monitoring and control. Ability of
module to perform intended operation is limited.
Red
Fault
Module
2000NET has detected a fault condition in module. Fault may have been
communicated over the Frame Bus, or may indicate a failure of the module
to respond over the Frame Bus.
Use
this
link
