8945EDA/-D — Instruction Manual 33
Specifications
Specifications
Table 5. 8945EDA and 8945EDA-D Specifications
Parameter Value
Input
Number and type of inputs 1 or 2 BNCs (DA1: J9, DA2: J10)
Input impedance 75 ohm
Input signal type Serial digital component conforming to the following formats:
• SMPTE 292M
• SMPTE 259M (143 Mbps, 177 Mbps, 270 Mbps, 360 Mbps)
• SMPTE 344M (540 Mbps)
• 4 Mbps to 1.5 Gbps with PN20 pseudonoise sequence, maximum
ratio of 19/1
• DVB-ASI
Signal level SDI 800 mV p-p ±10% max
Return loss • >15 dB 5 to 270MHz
• >10 dB to 1.5 GHz
Equalization Auto equalizing:
HD signals up to 125 m Belden 1694a
SD signals up to 330 m of Belden 1694a
Outputs
Number and type of outputs 8 BNCs
Output impedance 75 Ohm
Signal type Serial digital component conforming to the following formats:
• SMPTE 292M
• SMPTE 259M (143 Mbps, 177 Mbps, 270 Mbps, 360 Mbps)
• SMPTE 344M (540 Mbps)
• 4 Mbps to 1.5 Gbps with PN20 pseudonoise sequence, maximum
ratio of 19/1
• DVB-ASI
Signal level SDI 800 mV p-p ±10%
Return loss • >15 dB 5 to 270MHz
• >10 dB to 1.5 GHz
Error Checking Transparent to embedded EDH
Signal polarity Non-inverted
Power
Input power maximum
8945EDA
8945EDA-D
2.6 W
2.9 W
Mechanical
Frame Type GeckoFlex
Number of frame slots One slot
Rear module type 8900WE-R
Rear module retainer maximum screw torque 4-5 inch-lb./0.45-0.6Nm
