40 Aurora Transfer Instruction Manual September 11, 2006
Chapter 3 Configuring the Aurora Transfer System
Configure ASK Location: Archive MDI host
This page tells the Archive MDI host where to look for the ASK service, which runs
on the Aurora Transfer server. If the Archive MDI host is the Aurora Transfer Server,
this configuration has likely already been done.
Configure Media Frame Core ASK: Archive
Make sure the Archive MDI is registered with the ASK software component, as
explained in
“Configure Media Frame ASK: Register components” on page 26 .
http://localhost:280 ASK Location Open this page locally on the machine that hosts the Archive MDI.
Enter the name of the Aurora Transfer server
Port 9010 is required. See “Ports and services mapping” on page 20 .
Saves changes. Changes are lost if you leave the configuration page without
updating.
Always click Update… buttons after making changes
It is not necessary to restart a service to put these settings into effect.
