70 HD Wireless User’s Guide (v6.2)
Chapter 6 - Connectors
6.3 WCU connectors
6.3.1 Triax connector 1+2
TRIAX GENLOCK
CVBS
1
2
(OSD)
SERIAL DIGITAL OUTPUT
1
2
Data1
A ux
Sign
I / Com
RS232
2
A
udio out
1
1
2
1 2 3
Network
Signalling
connector
intercom
SDI outputs
1+2+3
CVBS
outputs
Triax 2
Power
Audio outputs
Data
Ethernet
Reference
Triax 1
Auxiliary
Pin Description
1 Inner pin: Signals + power
2 Inner shield: Return
3 Outer shield: Base station
housing
1
2
3 This socket is used to connect
the triax cable from the triax
output of the AMU.
Various types of Triax
connector are available by
request
