18 | KMV-3901/3911
4 Specifications
Video Inputs
Connector: BNC
SD-SDI
Signal: SMPTE 259M-C (270 Mbps), SMPTE 272M-1994
Formats: 525 and 625
Return loss: > 15 dB up to 270 MHz
Jitter: < 0.2 UI
Cable length: 250 m (820 ft) (Belden 1694A)
HD-SDI
Signal: SMPTE 292M-C (1.485, 1.485/1.001 Gbps),
SMPTE 272M-1994
Formats: 720p 59.94 Hz
1080p 29.97 Hz
1080i 50 Hz
1080i 59.94 Hz
Return loss: > 15 dB up to 1.5 GHz
Jitter: < 0.2 UI
Cable length: 100 m (328 ft) (Belden 1694A)
3G-SDI
Signal: SMPTE 424M-2006 (2.97, 2.97/1.001 Gbps)
Formats: 1920 × 1080p 59.94 Hz (Level A)
1920 × 1080p 50 Hz (Level A)
Return loss: > 10 dB up to 2.97 GHz
Jitter: < 0.2 UI
Cable length: 1 100 m (328 ft) (Belden 1694A)
Graphic converted to HD-SDI from KXI-DVI-Bridge
Signal: SMPTE 292M-C (1.485, 1.485/1.001 Gbps)
Formats: 1024 × 768 @ 60 (XGA)
1280 × 1024 @ 60 (SXGA)
1366 × 768 or 1368 × 768 @ 60 (WXGA)
1680 × 1050 @ 60 (WSXGA+)
1600 × 1200 @ 60 (UXGA)
Cable length: 100 m (328 ft) (Belden 1694A)
1 If you wish to use the HD-SDI monitoring outputs (see page 19) and configure them for a 1080p format, then the
multi-viewer supports a maximum cable length of 90 m (295 feet) at the video inputs. Refer to “Configuring the HD-
SDI Monitoring Output Format” in the “Setting Up Rooms” chapter of the Kaleido-X User’s Manual, for more
information.
