Switcher Products — Protocols Manual69
Editor Commands
The command specifies the auto transition rate in terms of frames ranging
from 000 to 999. Specify the auto transition rate in the command by sup-
plying three data bytes:
•
HD — The hundreds digit in BCD. The MSB is the “execute” bit.
•
TN — The tens digit in BCD.
•
UN — The units digit in BCD. The four MSBs are control bits to select
Key 1, 2, 3 and Key 4 rates in addition to the auto transition rate.
The format of the HD byte is provided in
The format of the TN byte is provided in
Table 61. HD Byte Format
Bit
7
6
5
4
3
2
1
0
X
0
0
0
X
X
X
X
Combination of 4 bits makes Hundreds digits
Rate value of 0 through 9 in BCD (0000 to 1001)
0 = Set rate only, do not perform the transition
1 = Set rate and perform the auto transition
Table 62. TN Byte Format
Bit
7
6
5
4
3
2
1
0
0
0
0
0
X
X
X
X
Combination of 4 bits makes Tens digits
Rate value of 0 through 9 in BCD (0000 to 1001)
