Switcher Products — Protocols Manual77

Editor Commands

Zodiak Bit-Mask Format

The two-byte bit mask allows the editor to specify any combination of
effects addresses 00 through 7FF. The LSB (bit 0) represents the first
address, and bit 10 represents the DPM 4 address. The top bits are “don't
care.” This format is used with the FE Effects Address.

Table 74. Zodiak Effects Addresses Byte Format

Bit

15

14

13

12

11

10

9

8

7

6

5

4

3

2

1

0

PGM-PST Mix

Mix/Effects 1

Mix/Effects 2

Mix/Effects 3

DSK

Miscellaneous (MISC)

DPM
