Chapter 2 Using the Profile Configuration Manager
12 Profile Family
• A single click opens the specific dialog box, closing a previously opened
box, if necessary. A double-click opens the specific dialog box but does not
close any other open dialog boxes. To close all open dialog boxes at once,
choose
Window | Close All .
All changes in a dialog box take place immediately. The Undo button will undo
changes from the time a dialog box was opened in the current tab of the dialog
box. The Undo button is dimmed if there is nothing to undo. The Help button
opens context-sensitive help related to the current dialog box.
By default, the toolbar and status bar are shown in the Configuration Manager
window. To hide the toolbar or status bar:
• Choose View | Toolbar or View | Status Bar .
Saving a Configuration File
It is possible to preserve a configuration for later use. You can save your current
overall configuration in a file and then load it later. Configuration files have a
.cfg extension. To save your current configuration in a file:
1. Choose File | Save Current Configuration . The Save As dialog box appears
(Figure 7).
Figure 7. Save As dialog box
2. Enter a file name in the File Name box—new.cfg in this example.
3. Press Enter or click Save. The current configuration is saved.
