DCR 4000 User’s Guide | Menu Structure
3-4
3.3
Tools & Settings menu
Press [SEL] to display the first three items:
SET TC OFFSET: This menu is used to set the offset value for the generated timecode. The
offset is applied to the LTC output connector during playback.
Press [SEL] to enter the offset.
Press [PLAY] to increase or [STOP] to decrease the value. The offset can be changed from -2
to +2 frames relative to the timecode. Press [ESC] to return to the Tools and Settings menu.
PLAY LOOP: When this is set ON the selected Take or All Takes will play continuously until
[STOP] is pressed. Press [SEL] to toggle between ON and OFF.
SET PREROLL TIME: On playback, the Venom can be set to give a preroll to allow external
devices to synchronise. Press [SEL] to allow preroll time entry.
Press [PLAY] to increase or [STOP] to decrease preroll time. Each press changes the value by
1 second in the range 0 to 8 seconds.
Press [ESC] to return to the Tools and Settings menu.
RECORD
RECORD
POWER
POWER
LIGHT
LIGHT
ESC
ESC
UP
UP
DOWN
DOWN
PLAY
PLAY
READY
READY
SEL
SEL
PLAY
PLAY
STOP
STOP
REC
REC
TOOLS AND SETTINGS
> SET TC OFFSET ↑
PLAY LOOP: OFF
SET PREROLL TIME ↓
RECORD
RECORD
POWER
POWER
LIGHT
LIGHT
ESC
ESC
UP
UP
DOWN
DOWN
PLAY
PLAY
READY
READY
SEL
SEL
PLAY
PLAY
STOP
STOP
REC
REC
TOOLS AND SETTINGS
TC OFFSET 0 FRAMES
- +
RECORD
RECORD
POWER
POWER
LIGHT
LIGHT
ESC
ESC
UP
UP
DOWN
DOWN
PLAY
PLAY
READY
READY
SEL
SEL
PLAY
PLAY
STOP
STOP
REC
REC
TOOLS AND SETTINGS
PREROLL TIME 4 SECS
- +
