Connections on Rear Panel
Connections on Rear Panel
Connections X1, X2, X3 meet the requirements for electrical
separation according to EN 50 178!
ID label
Power switch
Power input
Ground terminal Encoder inputs X1 to X3 Rubber feet with M4 thread
