HEIDENHAIN iTNC 530
309
8.6 SL Cy
cles
U
U
U
U
Milling depth
Q1 (incremental value): Distance
between the cylindrical surface and the floor of the
contour
U
U
U
U
Finishing allowance for side
Q3 (incremental
value): Finishing allowance on the slot wall. The
finishing allowance reduces the slot width by twice
the entered value.
U
U
U
U
Set-up clearance
Q6 (incremental value): Distance
between the tool tip and the cylinder surface
U
U
U
U
Plunging depth
Q10 (incremental value): Dimension
by which the tool plunges in each infeed
U
U
U
U
Feed rate for plunging
Q11: Traversing speed of the
tool in the tool axis
U
U
U
U
Feed rate for milling
Q12: Traversing speed of the
tool in the working plane
U
U
U
U
Cylinder radius
Q16: Radius of the cylinder on which
the contour is to be machined
U
U
U
U
Dimension type ? ang./lin.
Q17: The dimensions for
the rotary axis of the subprogram are given either in
degrees (0) or in mm/inches (1)
U
U
U
U
Slot width
Q20: Width of the slot to be machined
Example: NC blocks
63 CYCL DEF 28.0 CYLINDER SURFACE
Q1=-8
;MILLING DEPTH
Q3=+0
;ALLOWANCE FOR SIDE
Q6=+0
;SAFETY CLEARANCE
Q10=+3
;INFEED DEPTH
Q11=100
;FEED RATE FOR PLUNGING
Q12=350
;FEED RATE FOR MILLING
Q16=25
;RADIUS
Q17=0
;DIMENSION TYPE
Q20=12
;SLOT WIDTH
