HEIDENHAIN iTNC 530 397
1
0
.8 A
d
ditional F
unctions
7 U axis
8 V axis
9 W axis
Traverse range, 230 2 1 to 9 Negative software limit switch in axes 1 to 9
3 1 to 9 Positive software limit switch in axes 1 to 9
Nominal position in the REF system, 240 1 1 X axis
2 Y axis
3 Z axis
4 A axis
5 B axis
6 C axis
7 U axis
8 V axis
9 W axis
Nominal positions in the input system,
270 1 1 X axis
2 Y axis
3 Z axis
4 A axis
5 B axis
6 C axis
7 U axis
8 V axis
9 W axis
Status of M128, 280 1 - 0: M128 inactive, -1: M128 active
2 - Feed rate that was programmed with M128
Triggering touch probe, 350 10 - Touch probe axis
11 - Effective ball radius
12 - Effective length
13 - Radius setting ring
Group name, ID No. Number Index Meaning
