20
Co
nto
u
r Ap
proa
ch a
n
d
D
e
pa
rture
Departing tangentially on a straight line: DEP LT
8 Enter the distance between P
E
and P
N
as
Enter LEN > 0
Departing on a straight line perpendicular to the last contour point:
DEP LN
8 Enter the distance between P
E
and P
N
as
Enter LEN > 0
23 L Y+20 RR F100
24 DEP LT LEN12.5 F100
25 L Z+100 FMAX M2
23 L Y+20 RR F100
24 DEP LN LEN+20 F100
25 L Z+100 FMAX M2
X
Y
10
20
P
A
RR
P
S
R0
P
H
RR
RR
40 10
R10
35
20
X
Y
20
P
E
RR
P
N
R0
RR
12.5
X
Y
20
P
E
RR
P
N
R0
RR
20
