66 Introduction
2.4 Stat
us Displa
ys
Information in the status display
Symbol Meaning
Actual or nominal coordinates of the current position
Machine axes; the TNC displays auxiliary axes in
lower-case letters. The sequence and quantity of
displayed axes is determined by the machine tool
builder. Refer to your machine manual for more
information
The displayed feed rate in inches corresponds to one
tenth of the effective value. Spindle speed S, feed
rate F and active M functions
Program run started
Axis is clamped
Axis can be moved with the handwheel
Axes are moving under a basic rotation
Axes are moving in a tilted working plane
The function M128 (TCPM) is active
No active program
Program run has started
Program run is stopped
Program run is being aborted
ACTL.
X Y Z
F S M
TC
PM
