308 Programming: Special Functions
1
0
.1 Ov
erview of Special F
unctions
10.1 Overview of Special Functions
Press the SPEC FCT and the corresponding soft keys to access further
special functions of the TNC. The following tables will give you an
overview of which functions are available.
Main menu for SPEC FCT special functions
U Press the special functions key
Function Soft key Description
Define program defaults Page 309
Functions for contour and point
machining Page 309
Define the PLANE function Page 321
Define different DIN/ISO
functions Page 310
Define structure items Page 123
After pressing the SPEC FCT key, you can open the
smartSelect
selection window with the GOTO key. The
TNC displays a structure overview with all available
functions. You can rapidly navigate with the cursor or
mouse and select functions in the tree diagram. The TNC
displays online help for the specific functions in the window
on the right.
