EN
Mounting the inverter
Page 17 Operating Instructions for Powador 3200-6600_EN
6.1 Unpacking the inverter
CAUTION
Risk of injury due to high weight of the inverter (approx. 19-30 kg) !
› Observe the weight of the inverter during transport.
› Select suitable mounting location and mounting base.
› Use mounting material corresponding to or included with the base for mounting the inverter.
› Only mount the inverter with the help of a second person.
1
2
3
Figure 8: Unpacking the inverter Figure 9: Setting up the inverter
Key
1
Carton 3 Inverters
2 Protective packaging
Unpacking the inverter
1. Open carton at the front.
2. Remove installation material and documentation.
3. Slide inverter carefully out of the carton with the protective packaging.
4. Place the protective packaging back into the carton during mounting.
» Continue setting up the inverter.
6.2 Setting up the inverter
NOTE
Power reduction due to heat accumulation.
If the recommended minimum clearances are not observed, the inverter may go into power regula-
tion mode due to insufficient ventilation and the resulting heat build-up.
› Maintain minimum clearances.
› Ensure sufficient heat dissipation.
