pc200sdauto.v3 Issue no.2 19/10/09 Original Language Version
7. WET VACUUM CLEANING
inflow. the leave a gap at the top of the nozzle opening to
allow an air inflow. the machine is fitted with a float valve which
stops the suction action when the tank has reached its
maximum capacity. the user will notice an increase in motor
speed. When this happens, turn off the machine, disconnect
from power supply and empty the container either by removing
the power head and pouring the liquid out or by removing the
drain cap at the base of the container. after wet vacuuming,
turn the machine off and unplug from power supply. Empty the
container and clean and dry the inside and outside before
storage. Remember! after wet vacuuming the foam filter must
be removed and a cartridge filter must be fitted before dry
vacuuming again.
 WARNING! Ensure you read, understand and apply
Section 1 ‘Safety Instructions’. Reminder: Remove plug
from power supply before opening unit. DO NOT vacuum
solvents, explosives, inflammable and/or hazardous
liquids such as petrol, oil, spirits, paint, thinners, acids etc.
 WARNING! Not designed for liquid storage. Always
empty liquids after use and before storing.
7.1 Ensure the machine is unplugged from the power supply.
Make sure the tank is clean and free from dust and dirt.
7.2 Remove the cartridge filter and fit a foam filter over the filter
basket. Replace the top section onto the container.
7.3 to the same flexible hose as used in dry cleaning fit the
desired nozzle.
7.4 Ensure the switch is ‘off’ (position ‘0’) before plugging into
the power supply.
7.5 press the switch to ‘on’ (position ‘I’).
note: to vacuum large quantities of liquid, from a sink or
tank etc, do not immerse the nozzle completely in the liquid,
leave a gap at the top of the nozzle opening to allow an air
 WARNING! Ensure you read, understand and apply
Section 1 ‘Safety Instructions’. Reminder: DO NOT
vacuum hazardous substances. Use of an incorrect
cartridge filter will invalidate your warranty.
6.1 Ensure the machine is unplugged from the power supply.
6.2 Remove the top section and with the raised rim uppermost fit
the cartridge filter tube down over the filter basket and push
fully home. place the locking disc onto the top of the filter
and turn the locking bar until the latch drops into the slot in
the top of the filter cage. continue turning until the filter is
fully locked down. (see 2 below)
6.3 Reposition the head onto the drum body, and clip in place.
6.4 Insert the larger end of the flexible hose into the front inlet on
the container and lock in place. push the required attachment
onto the free end of the hose.
6.5 plug in the power supply.
6.6 switch to the ‘on’ (position ‘I’).
6.7 When you have completed vacuuming, press the switch to
‘off’ (position ‘o’) and unplug from power supply. Regularly
check the container and dispose of dust and debris when it
is 1/2 full.
6. DRY VACUUM CLEANING
5. SWITCH OPERATION
5.1 USE WITH VACUUM CLEANER ONLY.
the single bar position switches on the vacuum cleaner only.
5.2 USING VACUUM WITH DUST FREE TOOL
the double bar position is for the use of dust free tools. see
section 9.
9.1 connect the tool to the hose using the rubber adaptor supplied.
Ensure that the on/oFF switch is in the OFF position then
plug the dust free tool into the covered socket provided on
the front of the power head (see fig.1-16). Move the switch to
the double bar position. the vacuum cleaner will start
automatically when the tool is switched on. When the tool is
switched off the vacuum will continue to run for 10 seconds to
ensure that the tool and hose are left free of dust.
8. BLOWING
 WARNING! Wear a dust mask if blowing creates dust
that might be inhaled.
 WARNING! Always wear safety goggles when using the
unit for blowing.
 WARNING! Keep bystanders clear from blowing debris.
 WARNING! Make sure the container is empty before
using the unit as a blower.
8.1 Remove the hose from the vacuum port and insert the large
end of the hose into the blowing port on the other side of the
power head and twist to the right to lock it in place.
8.2 Fit the desired extension tube/nozzle to the free end of the
vacuum hose.
8.3 Ensure the on/oFF switch is in the central oFF position.
8.4 plug the unit into the mains power supply.
8.5 take firm hold of the loose end of the hose and select the
single bar position 'I' on the on/oFF switch to start the motor.
8.6 If the unit does not appear to be blowing, switch oFF and
check for blockages in the hosepipe.
9. USING DUST FREE TOOLS
