Livarno 54006 - Manual (Page 18)

English
Mounting, switching on, malfunctions
Observe all of the instructions and warnings. Improper use or incorrect operation can lead to serious physical injury
(e.g. from electric shock or burning) and substantial material damage (e.g. from fire).
Storage and transport
Store and transport the lamp only in its original packaging. Protect packaged light from mechanical impact, moisture, frost and dust.
Comes with
Lamp, Bulb(s) included!
Unpacking
Take all the parts of the lamp out of the box and remove the packaging material. Put all the parts of the lamp on a soft surface in
front of you, such as a carpet. Check the parts for any possible visible damage.
Mounting and electrical installation
The mounting and electrical installation must be carried out by a qualified electrician.
Switch off (or remove) the mains fuse before mounting and installing the light (see illus. p.2,A).
Make sure the power is not connected by using an appropriate electricity indicator.
1. Loosen the screw on the ceiling housing in an anti-clockwise direction (see illus. p.2,B1).
2. Slide the cover from the assembly plate (see illus. p.2,B2-3).
3. Hold the assembly plate to the ceiling and mark the drill holes with a suitable marker pen.
4. Drill 4 holes at the marked positions and insert dowels.
5. Guide the connecting cable through the opening in the mounting (see illus. p.2,B4).
6. Screw the mounting bracket tightly to the ceiling (see illus. p.2,B5).
7. Connect the power cable to the designated terminalblock: L / N and earth wire (see illus. p.2,B6).
8. Slide the cover back onto the assembly plate (see illus. p.2,B7-8).
9. Tighten the cover screws on the assembly plate in a clockwise direction (see illus. p.2,B9).
10. Put the light cover on (see illus. p.2,Bi).
11. Tighten the lateral cover in a clockwise direction, including the rubber washer, as far as it will go (see illus. p.2,Bj).
12. Switch the fuse back on (see illus. p.2,C).
Switching on
Switch the light on / off with the mains switch
Disposal of packaging
Dispose of the packaging material, sorting it according to type.
Keep packaging and wrapping away from children. Danger of suffocation!
Damage and malfunctions
In the case of malfunction or damage to the lamp, disconnect it permanently from the domestic electrical installation. Do not use it
anymore. Repairs should be carried out only by a qualified electrician or at the service centre. Never attempt to repair the lamp
yourself.
01/2011; Lidl - Block 5; IAN69246; 54006 17/24
