Chapter 2 Command System RIGOL
DG1000Z Programming Guide 2-51
:MMEMory:LOAD:DATA
Syntax :MMEMory:LOAD:DATA[1|2] <file_name>
Description Load the specified arbitrary waveform file in the current directory of the external memory
into the specified channel.
Parameter Name Type Range Default
[1|2] Discrete 1|2 1
<file_name> ASCII string
The filename of the arbitrary
waveform file in the current
directory of the external
memory
None
Explanation  This command is only applicable to the external memory.
 [1|2] denotes the channel (CH1 or CH2) into which will the specified arbitrary
waveform file in the current directory of the external memory be loaded. When it is
omitted, the file will be loaded into CH1.
 <file_name> is the filename of the arbitrary waveform file in the specified directory
of the external memory and it is a string enclosed in double quotation marks, for
example, "Rigol4.RAF".
Example Assume that the current directory is D:\Rigol,
:MMEM:LOAD:DATA "Rigol4.RAF" /*Load the arbitrary waveform file Rigol4.RAF in the
current directory of the external memory
(D:\Rigol) into the current channel*/
:MMEMory:LOAD:STATe
Syntax :MMEMory:LOAD:STATe <file_name>
Description Load the specified state file in the current directory of the external memory.
Parameter Name Type Range Default
<file_name> ASCII string
The filename of the state file
in the current directory of the
external memory
None
Explanation  This command is only applicable to the external memory.
 <file_name> is the filename of the state file in the current directory of the external
memory and it is a string enclosed in double quotation marks, for example,
"Rigol0.RSF".
Example Assume that the current directory is D:\.
:MMEM:LOAD "Rigol0.RSF" /*Load the state file Rigol0.RSF in the external memory
(D:\)*/
