9.3. RTCA DO-160F Qualifications for Displays
The table below shows the DO-160F compliance of the 7004 series displays and their
corresponding bases. Omitted categories are not applicable to these products or their expected
installations. Reference the Qualification Test Reports for specific details.
Table 5 The 7004 displays are compliant with the following DO-160F test criteria
Description Section Category Comments
Temperature and Altitude 4
Ground Survival/Short-Time Operating
Low Temp
4.5.1 A1
Operating Low Temperature 4.5.2 A1
Ground Survival/Short-Time Operating
High Temp
4.5.3 A1
Operating High Temperature 4.5.4 A1
Altitude 4.6.1 A1
Decompression 4.6.2 A1
Overpressure 4.6.3 A1
Temperature Variation 5
Temperature Variation 5.3.1 C
Humidity 6
Humidity 6.3.1 A
Operational Shocks & Crash Safety 7
Operational Shocks 7.2.1 B (6G)
Crash Safety (Impulse) 7.3.2 B (20G)
Crash Safety (Sustained) 7.3.3 B (20G) SDI / (9G) CVBS
Vibration 8
Random Vibration – Fixed Wing Aircraft 8.5.2 S (Curve B)
Magnetic Effect 15
Magnetic Effect 15.3 Z
Power Input 16
Normal Operating Conditions (DC) 16.6.1
Average Value Voltage (DC) 16.6.1.1 Z
Ripple Voltage (DC) 16.6.1.2 Z
Momentary Power Interruptions (DC) 16.6.1.3 Z
Normal Surge Voltage (DC) 16.6.1.4 Z
Engine Starting Under Voltage Operation
(DC)
16.6.1.5 Z
