Rosen Aviation 7” Widescreen Display
Document Number: 106211 Revision: B
Date: 04/17/14
Template: 4.4.1.6FM2; Revision A; 12/06/12 Page 30 of 31
9.4. Supported Video Resolutions
9.4.1. CVBS/Composite Resolutions
NTSC (480i/29)
PAL (576i/25)
SECAM (576i/25)
RS-170 B&W (480i/29)
The software continually checks and chooses the appropriate color decoder (NTSC,
PAL, or SECAM) based on the analog input signal.
9.4.2. SDI Resolutions
SMPTE 259M
480i/29
576i/25
SMPTE 292M
720p/50, 720p/59, 720p/60
1080i/25, 1080i/29, 1080i/30
1080p/23, 1080p/24, 1080p/25, 1080p/29, 1080p/30
SMPTE 424M
1080p/50, 1080p/59, 1080p/60
10. DEFINITIONS
3G HD-SDI Newer, high-definition serial digital interface with a single 2.970 G/bit/s serial
link
A Amps
AF Audio frequency
CFR Code of Federal Regulations
CVBS Color Video Blanking and Sync (Composite video signal)
DVI Digital Visual Interface
EUT Equipment under test
HD High Definition
HDMI High Definition Multimedia Interface
HD-SDI High Definition Serial Digital Interface
LCD Liquid Crystal Display
LED Light emitting diode
