17” SlimLine LCD Page 3
Introduction and Display Overview
Introduction and Display Overview
Welcome to the 1700 Technical Manual for the 17" SlimLine
LCD Display. This manual provides an overview of display
details including:
• Pinouts
• Installation
• Operation
• Troubleshooting
• Specifications
The 1700 model includes the following features:
• 17" Diagonal Viewing Area
• NTSC/PAL/SECAM/RS-170 (Composite video)
• Analog RGB (Computer video)
• 1280 x 1024 Screen Resolution (SXGA)
• On Screen Display (OSD) functions
• Status LED
• Configurable Picture in Picture (PIP)
• 28 Volt Operation
• Front Switch Panel
• DO160D Compliant
The 1700 model accommodates the following optional
controllers (Available separately):
• IR Remote Codes Available
• External 7-button controller
