Rosen Aviation Displays

Pinouts

Pin

Display Signal

14

Reserved

15

Digital GND (RGB video select return)

16

Digital GND

17

Digital GND

A1

Signal Red

A1

Shield Red Return

A2

Signal Green

A2

Shield Green Return

A3

Signal Blue

A3

Shield Blue Return

A4

Signal Composite Video

A4

Shield Composite Video Return
