5 INSTALLATION AND START-UP
5.1 INSPECTION
• The Opal Pro has been packaged to protect it from damage caused by normal handling
during shipment, however mishandling may cause damage to the Opal Pro. Unpack the unit
as soon as it is received and check for any shipping or storage damages.
• If damage is found, notify the carrier. Any damage claim must be filed by the customer
since all shipments are F.O.B. Manufacturers plant unless otherwise specified.
• If the Opal Pro is not installed when received, store it in a clean, dry, well ventilated area,
free from heat, humidity, oil, dust, and metal particles.
5.2 SAFETY PRECAUTIONS
CAUTION
Equipment is at line voltage when AC power is connected.
Pressing "STOP" pushbutton does not remove AC mains potential.
All phases must be disconnected before it is safe to work on machinery, touch motor terminals or
control equipment parts.
• The electrical code requires all equipment, starter, motor, operator station, etc. to be
grounded properly.
• An incoming circuit breaker or disconnect switch must be locked open before wiring or
servicing this starter, motor, or other related equipment. This equipment must be installed
and serviced only by qualified personnel, familiar with this starter.
• The user is responsible for ensuring that proper short circuit protection is provided by either
a circuit breaker or HRC fuses.
5.3 MOUNTING GUIDELINES
• Standard Nema 1 Opal Pro Starters must be installed indoors in a well ventilated area, free
from heat, humidity, oil, dust and metal particles.
• One foot of clearance must be kept all around in a natural cooled unit. The equipment must
be mounted away from any heat source. See Section 2 for additional specifications.
• Be aware that the heatsink may reach 70° C / 158°F during normal operation. Do not
install the starter in contact with any material that cannot accept this temperature.
• The starter must be mounted vertically and where it will not experience excessive shock or
vibration.
