PKV101
Service
- 24 -
31. Re-install the other half of the seal. by pushing tight
against the other half.
Note:
Lubricating with a small amount of soap detergent
and water will ease installation.
30. Push the mechanical seal into the cavity making sure it
is seated properly and even. Using your two thumbs
works great. If the backplate was removed, then in-
stall the seal into the backplate before putting on
crankshaft.
Note:
Lubricating with a small amount of soap detergent
and water will ease installation signifi cantly.
32. Re-install the spring. It can be installed in either direc-
tion.
29. The seal will have some colored marks indicating that
this is the back side. Do not install towards the rotating
seal. The marks should face the engine.
