6. Put the KVM module into the console form the back. There are two ways to install the
KVM module in suitable position, users can fix KVM module with the KVM
accessories (Both sides) or the extra Rack- mounted Screws (Bothsides).
KVM accessories (L& R) X2
Extra rack- mounted Screws X8
7. Finish installation as below.
