MVI56-104S ♦ ControlLogix Platform Ladder Logic
IEC 60870-5-104 Server Communication Module User Manual
Page 76 of 188
ProSoft Technology, Inc.
November 18, 2009
3.3.6 Cold Boot (9999) Block
This block is sent from the ControlLogix processor to the module (output image)
when the module is required to perform the cold boot (hardware reset) operation.
This block is sent to the module when a hardware problem is detected by the
ladder logic that requires a hardware reset. The following table describes the
format of the control block.
Offset Description Length
0 9999 1
1 to 247 Spare 247
