Samson Go Mic USB Microphone for Mac and Windows Computers (Silver) - Manual (Page 7)

5
Go Mic Layout
9
6
1
2
3
4
5
1. Windscreen – Dual stage grill protects the
capsules and helps reduce wind noise and p-
popping.
2. Capsules – Dual, internally shock isolated
10mm capsules provide both Cardioid and
Omni polar patterns.
3. LED – The dual color Power/Clip LED lights
green to indicate power, and flashes red when
the input signal is clipping.
4. Diecast Base – The molded zinc base is
weighted and shock isolated to provide a sturdy
solution for desktop applications.
5. Mic Stand Mount – A standard Euro-mount mic
stand mounting hole and included adapters
allow you to attach the Go Mic to a standard
microphone stand.
6. Clip – Integral mounting clip for easy set-up
and installation up on just about any laptop
computer.
8. USB – Mini-B size USB connector for interfacing
with your PC or Mac.
7. Phones - 1/8-inch (.35mm) stereo jack for
connecting headphones or studio monitors.
9. Pattern switch – Selector switch used to set the
microphone for Cardioid, Cardioid with a 10 dB
Pad, or Omni pick-up pattern.
