147

Press the down arrow button to select

Yes

to start the cleaning. The cleaning can take up to 37

minutes.

Press the

button to start the cleaning cycle.

When the cleaning cycle is finished, the

power light stops flashing and a confirmation screen

appears.

Caution:

Never turn off the product during a cleaning cycle or you may damage it.

Print another nozzle check pattern to view the results of the cleaning.

If nozzles are still clogged, turn off the printer and leave it off overnight. If nozzles are still clogged after
some time, contact Epson for support.

Parent topic:

Print Head Maintenance

Related references

Administrator Menu Settings

Print Head Alignment

If your printouts become grainy or blurry, you notice misalignment of vertical lines, or you see dark or
light horizontal bands, you may need to align the print head.

Before you align the print head, note the following:

• Alignment varies depending on the loaded media. Align the print head using the media on which you

want to print and select the correct paper type as the

Paper Type

setting.

• Run a nozzle check before you align the print head. If there are any gaps in the nozzle check pattern,

clean the print head.

Aligning the Print Head Automatically Using a Computer Utility
Aligning the Print Head Automatically Using the Product Control Panel
Aligning the Print Head Manually Using the Product Control Panel
