2-1 Chapter 2: Setup
2.1 Detaching the Base (for VESA Wall
Mount)
To detach the base, perform the following:
1. Disconnect power and signal cables. Carefully place the monitor on
the EPS foam, with the screen facing down.
2. Remove the stand cover.
3. Use the L-shaped screwdriver to remove the four screws. Then
remove the stand assembly.
4. Remove the four rubber pads. Then align and install the wall mount
bracket on the rear of the monitor.
Screw holes for
VESA wall mount
(100 x 100 mm)
• We recommend that you cover the table surface with soft cloth to prevent
damage to the monitor.
• Hold the base while removing the screw.
• The VESA wall mount kit ( 100 x 100 mm) is purchased separately.
• Use only the UL Listed Wall Mount Bracket with minimum weight/load
22.7kg (Screw size: M4 x 10 mm).
