3-13

Chapter 3: General Instructions

3.2 Specifications

Model

VY249HE/VY249HE-W

Panel Size

23.8 inches diagonal

(Active Display Area: 527.04 (H) x 296.46 (V) mm)

Max. Resolution

1920 x 1080

Brightness (Typ.)

250 cd/m

2

Contrast Ratio (Typ.)

1000:1

Viewing Angle (CR≤10)

178

°

(V); 178

°

(H)

Display Colors

16.7M colors (6 bits + A-FRC)

Response Time

5ms (GTG)

Terminals

Inputs:

HDMI x 1, VGA x 1

Audio Output:

Headphone

Power Consumption

16W(Max)

Power Consumption

(Energy Star On mode)

11.6W

Standby Power

Consumption

< 0.5W at AC110V~ AC220V

Power Off Power

Consumption

< 0.3W at AC110V~ AC220V

Phys. Dimension (incl. base)

(HxWxD)

393 x 541 x 185 mm

Box Dimension (HxWxD)

392 x 603 x 130±5 mm

Net Weight (incl. stand)

3.38 kg

Gross Weight (Esti.)

4.62 kg

Voltage Rating

100~240V at 50/60Hz

Temperature

Operating temperature: 0 ~ 40˚C
Storage temperature: -30 ~ 65˚C

Accessories

Power cord, Quick Start Guide, Warranty card, L-shaped

screwdriver, 4 screws, HDMI cable (optional), VGA cable

(optional)

Compliance and

Standards

CE, CB, FCC, CCC, CU, RCM, UL/cUL, UKrSEPRO, BSMI,

KC(EK)/ MSIP(KCC)/ E-Standby(E-Boy), PSE, VCCI, Energy

Star 8.0, HDMI, Windows 7 & 8.1 & 10 WHQL, MEPS, TCO8.0,

China Energy Label, EU Energy Label, CEC, RoHS, WEEE,

EuP(Energy Saving Only), EPEAT Bronze (VY249HE only),

PC Recycle, J-MOSS, PSB, TUV Low Blue Light, TUV Flicker

Free

*Specifications subject to change without notice.
