Image configure the image settings – Asus Republic of Gamers Swift PG42UQ 41.5" 4K HDR 138 Hz Gaming Monitor User Manual
Page 23
3-2
Chapter 3: General Instruction
2. Image
Configure the image settings.
Brightness 30
Uniform Brightness
Contrast 80
VividPixel
HDR Setting
Aspect Control
Blue Light Filter
MOVE/ENTER
BACK
EXIT
Input Select
System Setup
MyFavorite
Color
Gaming
PIP/PBP Setup
Racing Mode
ROG Swift PG42UQ HDR OFF
DisplayPort 3840x2160 120Hz
• Brightness
: Adjust the brightness level.
• Uniform Brightness
: With the feature enabled, the system will
not adjust the maximum brightness of the screen when the screen
is displayed in a different screen size.
• Contrast
: Adjust the contrast level.
• VividPixel
: Enhance the outline of the displayed picture and
generates high-quality images on screen.
• HDR Setting:
Set the HDR mode to ASUS Gaming HDR, ASUS
Cinema HDR, or Console HDR. The HDR brightness can be
adjusted when the Brightness Adjustable function is enabled.
• Aspect Control
: Adjusts the aspect ratio to
Full,Equivalent, 1:1,
16:9 (24”W), 16:9 (27”W), and 21:9 (34”W).
• Blue Light Filter:
Reduce the energy level of blue light emitted
from the LED backlight.
• Level 0:
No change.
• Level 1~4:
The higher the level, the less blue light is
scattered. When Blue Light Filter is activated,the default
settings of Racing Mode will be automatically imported.
Between Level 1 to Level 3, the Brightness function is user-
configurable. Level 4 is optimized setting. The Brightness
function is not user-configurable.
• The Monitor uses low blue light panel and compliance with
TÜV Rheinland Low Blue Light Hardware Solution at factory
reset/default setting mode (Brightness: 90%, Contrast: 80%,
CCT: 6500K, Preset mode: Racing mode, Power Setting:
YES).
