45
Chapter 8 Reference
8-4. Specifications
LCD Panel Type IPS (Anti-Glare)
Backlight Wide color gamut LED
Size 68.4 cm (26.9 inch)
Resolution 3840 dots x 2160 lines
Display Size (H x V) 596.2 mm x 335.3 mm
Pixel Pitch 0.155 mm x 0.155 mm
Pixel Density 164 ppi
Display Colors Approx. 1073.74 million colors (10 bit colors)
Viewing Angle (H x V, typical) 178˚ / 178˚
Contrast Ratio (typical)
1000:1 (When "DUE priority" setting is "Brightness")
Response Time (typical) Black → White → Black: 16 ms
Gray-to-gray: 10 ms
Color Gamut Display (typical) NTSC ratio 103 %
Adobe ® RGB coverage: 99 %
Video Signals Input Terminals USB Type-C (DisplayPort Alt Mode, HDCP 1.3 compatible) x 1
DisplayPort (HDCP 1.3 compatible) x 1
HDMI (HDCP 1.4, HDCP 2.2, Deep Color compatible) *1 x 1
*1 Not compatible with HDMI CEC function (mutual control
function).
Horizontal scan frequency USB Type-C (DisplayPort Alt Mode): 25 kHz to 137 kHz
DisplayPort: 25 kHz to 137 kHz
HDMI: 15 kHz to 135 kHz
Vertical scan frequency USB Type-C (DisplayPort Alt Mode): 23 Hz to 61 Hz (For 720 x
400: 69 Hz to 71 Hz)
DisplayPort: 23 Hz to 61 Hz (For 720 x 400: 69 Hz to 71 Hz)
HDMI: 23 Hz to 61 Hz (For 720 x 400: 69 Hz to 71 Hz)
Frame Synchronization mode 23.75 Hz to 30.5 Hz, 47.5 Hz to 61.0 Hz
Dot clock (Max.)
USB Type-C (DisplayPort Alt Mode): 598.3 MHz
DisplayPort: 598.3 MHz
HDMI: 600 MHz
USB Port Upstream USB Type-C (USB 3.1 Gen 1) x 1
USB Type-B (USB 3.1 Gen 1) x 1
Downstream USB Type-A (USB 3.1 Gen 1) x 2
USB Type-A (USB 2.0) x 2
Standard USB Specification Revision 3.1 Gen 1
USB Specification Revision 2.0
Communication Speed 5 Gbps (super) *2 , 480 Mbps (high), 12 Mbps (full), 1.5 Mbps
(low)
*2 The downstream port (USB 2.0) does not support 5 Gbps.
Supply Current Upstream USB Type-C (USB 3.1 Gen 1): Maximum 60 W
Downstream USB Type-A (USB 3.1 Gen 1): Maximum 900 mA per port
USB Type-A (USB 2.0): Maximum 500 mA per port
Power Input 100-240 VAC ±10 %, 50/60 Hz 1.70 A - 0.75 A
Maximum Power Consumption 168 W or less
Power Save Mode
1.0 W or less (Only for DisplayPort input, when "Compatibility
Mode" is set to "Off" and no USB device is connected)
Standby Mode 1.0 W or less (When there is no input signal, "Compatibility
Mode" is set to "Off", and no USB device is connected)
