1.
Remove the four screws from the VESA holes located on the rear of the monitor head.
2.
To attach the monitor head to a swing arm or other mounting device, insert four mounting screws
through the holes on the mounting device and into the VESA screw holes on the back of the monitor
head.
Connecting the cables
In addition to details about how to connect a cable, this section contains information about how your monitor
functions when you connect certain cables.
NOTE:
The monitor ships with select cables. Not all cables shown in this section are included with the
monitor.
Connecting the cables
9
