Philips 498P9Z 48.8" 1440p HDR Curved Monitor - Manual (Page 15)

13
2. Setting up the monitor
2.5 Remove the Base Assembly
for VESA Mounting
Before you start disassembling the
display base, please follow the
instructions below to avoid any possible
damage or injury.
1. Place the display face down on a
smooth surface. Pay attention not to
scratch or damage the screen.
2. Loosen the assembly screws, then
detach the neck from the display.
2
1
Note
This display accepts a 100mm x 100mm
VESA-Compliant mounting interface.
100mm
100mm
-5°
0° 90°
* Display design may differ from those
illustrated.
Warning
• To avoid potential screen damage,
such as panel peeling, ensure that
the monitor does not tilt downward
by more than -5 degrees.
• Do not press the screen while
adjusting the angle of the monitor.
Grasp only the bezel.
Warning
This product is curve design, when
attach / detach the base, place the
protective material under the monitor
and do not press down the monitor to
avoid the damage.
